CREA METAL , CREA SWISS welding gauge for frame construction

“One-man device”: set the external dimensions, place the profiles, adjust the height difference and weld completely on both sides.

Whether its steel windows, fire doors or angular steel frames: with the CREA-SWISS, all workers can produce perfect frames quickly, precisely and profitably.

Swiss welding table for welding steel joinery.

"One-man device": set the external dimensions, insert the profiles, adjust the height difference and completely finish the weld on both sides.

Whether steel windows, fire doors or angle steel door frames: with the CREA-SWISS frame welding fixture, all employees can produce perfect frames quickly, precisely and economically.

Setting up the frame welding template takes just a few minutes. The frame width is adjusted symmetrically to the longitudinal axis using a reduced gear unit. The measurement can be easily read on the ergonomically positioned digital display. The frame height is adjusted directly at the corner stops - measuring scales are integrated.

Technical data
Chedjwcyqhspfx Ab Nec
Maximum frame size: 3000 mm x 2400 mm
Minimum frame size: 470 x 610 (510) mm
Profile height: up to 115 mm
Height tolerance compensation: -1 mm to +1 mm
Weight: 280 kg

Advantages:
One-person device

Completely welded in one clamp

Precise alignment for precise frame construction

Precise adjustment of miter surfaces

Rotate around the longitudinal axis

Mobile workstation on wheels

Rung supports for doors with crossbars (option)

For all types of frames
